DS1307 IC - (SMD Package) - Real Time Clock (RTC) IC

The MCP30083008 devices are successive approximation ID-bit Analog- to-Digital (AID) converters With on-board sample and hold circuitry. The MCP3008 is programmable to provide four pseudo-differential input pairs or eight single-ended inputs. Differential Nonlinearity (DNL) and Integral Nonlinearity (INL) are specified at ± I LSB_ Communication With the devices is accomplished using a simple serial interface compatible With the SPI protocol. The devices are capable Of conversion rates Of up to 200 ksps. The MCP3008 devices operate over a broad voltage range (2_7V - 5_5V)_ Low-current design permits operation With typical standby currents Of only 5 nA and typical active currents Of 320 PA. The MCP3008 is offered in 16- pin PDIP and SOIC packages. Features:- • 10-bit resolution • ± 1 LSB max DNL • ± 1 LSB max INL • 4 (MCP3004) or 8 (MCP3008) input channels • Analog inputs programmable as single-ended or pseudo-differential pairs • On-chip sample and hold • SPI serial interface (modes 0,0 and 1,1) • Single supply operation: 2.7V - 5.5V • 200 ksps max. sampling rate at VDD = 5V • 75 ksps max. sampling rate at VDD = 2.7V • Low power CMOS technology • 5 nA typical standby current, 2 µA max. • 500 µA max. active current at 5V • Industrial temp range: -40°C to +85°C • Available in PDIP, SOIC and TSSOP packages Applications:- • Sensor Interface • Process Control • Data Acquisition • Battery Operated Systems Specification:- Parameter Values Voltage Range on Any Pin Relative to Ground -0.5V to +7.0V Operating Temperature Range : Commercial 0°C to +70°C Industrial -40°C to +85°C Storage Temperature Range -55°C to +125°C Soldering Temperature +260°C for 10 seconds Related Document:- DS1307 IC SMD Data Sheet
