Hongfa 24V 8A DC HF68F/024-1HSB 4 Pin High Power SPST Relay
Hongfa 24V 8A DC HF68F/024-1HSB 4 Pin High Power SPST Relay
Miniature high power relay offers low height, 8A switching capability, 5kV dielectric strength (between coil and contacts) and environmentally friendly product (RoHS compliant) and meets VDE 0700, 0631 reinforce insulation. Features: 8A switching capability 5kV dielectric strength (between coil and
+ 18% GST (added at checkout)
In stock — 1476 units ready
- 8A switching capability
- 5kV dielectric strength (between coil and contacts)
- Low height: 12.5 mm
- Creepage distance >8mm
- Meeting VDE 0700, 0631 reinforce insulation
- Product in accordance to IEC 60335-1 available
- 1 pole configurations available
- UL insulation system: Class F
- Plastic sealed and flux proofed types available
- Brand : Hongfa
- Coil Voltage (DC) : 24 V
- Contact Arrangement : 2 Form C
- Contact Current Rating :8 A
- Termination : PCB
- Construction : Plastic sealed
- Mounting : DIP
- Contact capacity : AgNi+Au plated
- Contact plating : Au plated
- Release time : < 4ms
- Coil power : 200mW
- Insulation resistance :1000MOhm
- Dielectric strength (between coil & contacts) : 2000VAC 1min
- Operate time : < 7ms
- Ambient temperature : -40~85C
- Max Switching Voltage (VDC) : 120VDC
- Max Switching Voltage (VAC : 240VAC
- Max Switching Current (AC) : 24AC
- Weight: : 5gm
- Electrical endurance: 100000
- Size: 20.0x10.0x11.5mm
Buying in bulk?
Get volume pricing, GST invoicing and stock availability for larger quantities of this item.
Miniature high power relay offers low height, 8A switching capability, 5kV dielectric strength (between coil and contacts) and environmentally friendly product (RoHS compliant) and meets VDE 0700, 0631 reinforce insulation. Features: 8A switching capability 5kV dielectric strength (between coil and contacts) Low height: 12.5 mm Creepage distance >8mm Meeting VDE 0700, 0631 reinforce insulation Product in accordance to IEC 60335-1 available 1 pole configurations available UL insulation system: Class F Plastic sealed and flux proofed types available Specifications: Brand : Hongfa Coil Voltage (DC) : 24 V Contact Arrangement : 2 Form C Contact Current Rating :8 A Termination : PCB Construction : Plastic sealed Mounting : DIP Contact capacity : AgNi+Au plated Contact plating : Au plated Release time : < 4ms Coil power : 200mW Insulation resistance :1000MOhm Dielectric strength (between coil & contacts) : 2000VAC 1min Operate time : < 7ms Ambient temperature : -40~85C Max Switching Voltage (VDC) : 120VDC Max Switching Voltage (VAC : 240VAC Max Switching Current (AC) : 24AC Weight: : 5gm Electrical endurance: 100000 Size: 20.0x10.0x11.5mm Mechanical endurance : 100000000 Package Includes: 1 x Hongfa 24V 8A DC HF68F/024-1HSB 4 Pin High Power SPST Relay
