Hongfa 5V 16A DC HF115F-Q/005-1H3 6-Pin SPST Power Relay with Metal Holder Attached

Hongfa 5V 16A DC HF115F-Q/005-1H3 6-Pin SPST Power Relay with Metal Holder Attached

Hongfa 5V 16A DC HF115F-Q/005-1H3 6-Pin SPST Power Relay with Metal Holder Attached Features: Ambient temperature up to 125 ℃ 5kV dielectric strength (between coil and contacts) Low height: 15.7mm Creepage distance >8mm Meeting VDE 0700, 0631 reinforce insulation UL94, V-0 flammability class Product

+ 18% GST (added at checkout)

In stock — 242 units ready

• Ambient temperature up to 125 ℃
• 5kV dielectric strength (between coil and contacts)
• Low height: 15.7mm
• Creepage distance >8mm
• Meeting VDE 0700, 0631 reinforce insulation
• UL94, V-0 flammability class
• Product in accordance to IEC 60335-1 available
• UL insulation system: Class F
• Type : HF115F-Q/005-1H3
• Switching Current (A,Res.load) : 16A
• Contact arrangement : 1 Form A
• Coil version : single contact
• Terminal Type : Quick connect terminals
• Mounting : PCB-THT
• Construction : Flux proofed
• Terminals : Quick connect terminals horizontal
• Contact material : AgNi
• Sort : Standard
• Coil voltage : 5V
• Coil power: Approx 0.4W
• Insulation standard : Class F
• Coil voltage form : DC
• Rated voltage(V) : 250VAC
• Volume（mm³) : 45.0×12.7×15.7 (mm)
