MT3608 High Efficiency Step Up Converter IC - (SMD SOT23-6 Package)

The MT3608 is a constant frequency, 6-pin SOT23 current mode step-up converter intended for small, low power applications. The MT3608 switches at 1.2MHz and allows the use of tiny, low-cost capacitors and inductors 2mm or less in height. Internal soft-start results in a small inrush current and extends battery life. The MT3608 features automatic shifting to pulse frequency modulation mode at light loads. Featured by Sharvi Electronics The MT3608 includes under-voltage lockout, current limiting, and thermal overload protection to prevent damage in the event of an output overload. The MT3608 is available in a small 6-pin SOT-23 package. Specifications:- Manufacturer: Aerosemi Part No: MT3608 Input Voltage: 2V ~ 24V Output Voltage: Up ~ 28V Output Voltage: Adjustable Switch Current Limit: Internal 4A Switching Frequency: 1.2MHz Fixed Efficiency: up ~ 97% Integrated 80mΩ Power MOSFET Internal Compensation Automatic Pulse Frequency Modulation Mode at Light Loads Package: SOT23-6 Applications:- Battery-Powered Equipment Set-Top Boxed LCD Supply DSL and Cable Modems and Routers Networking cards powered from PCI. Package Includes:- 1 x MT3608 High Efficiency Step Up Converter IC - (SMD SOT23-6 Package)
