Nextion 5 inch BASIC NX8048T050 LCD TFT HMI Touch Display

Nextion NX8048T050 5.0 LCD TFT HMI Intelligent Touch Display is a seamless Human Machine Interface (HMI) solution that provides a control and visualization interface between a human and a process, machine, application or appliance. Nextion is mainly applied to the Internet of thing (IoT) or consumer electronics field. It is the best solution to replace the traditional LCD and LED Nixie tube. Nextion includes a hardware part (a series of TFT boards) and a software part (theNextion editor). The Nextion TFT board uses only one serial port to communicate. It lets users avoid the hassle of wiring. We noticed that most engineers spend much time in application development but get unsatisfactory results. As a solution to this situation, Nextion editor has mass components such as button, text, progress bar, slider, instrument panel etc. to enrich the interface design. Furthermore, the drag-and-drop function ensures that users spend less time in programming, which will reduce 99% of their development workloads. With the help of this WYSIWYG editor, designing a GUI is a piece of cake. Its easy to adapt Nextion family HMI to existing projects. Users just need to provide it a UART. Nextion 5.0 HMI Arduino TFT Lcd Intelligent Display Module Screen with integrated 4-wire Resistive Touch Panel 800480 NX8048T050 is a powerful 5.0 HMI, which is the member of Nextion family. Features include: a 5.0 TFT 800480 resistive touchscreen display, 16M Flash, 2KByte RAM, 65k colors. Features: Compatible with Raspberry Pi A+, B+, and Raspberry Pi 2, Arduino 800 x 480 Resolution RGB 65K true to life colors TFT Screen with integrated 4-wire Resistive Touch Panel For Raspberry Pi and Arduino Easy 4 pin interface to any TTL Serial Host For Arduino 16M Flash memory for User Application Code and Date Onboard micro-SD card for firmware upgrade Visual Area:108mm(L)64.8mm(W) Adjustable Brightness:0~230 nit, the interval of adjustment is 1% 5V410mA power consumption CE/EMC, RoHS certified (certificates) Interfaces Performance: Test Conditions Min Typical Max Unit Serial Port Baudrate Standard 2400 9600 115200 bps Output High Voltage IOH=-1mA 3.0 3.2 V Output low Voltage IOL=1mA 0.1 0.2 V Input High Voltage 2.0 3.3 5.0 V Input low Voltage -0.7 0.0 1.3 V Serial Port Mode TTL Serial Port 4Pin_2.54mm USB interface NO SD card socket Yes (FAT32 format), support maximum 32G Micro SD Card Technical support: For technical support, please open a ticket onItead Support System. Package Includes: 1 x Nextion NX8048T050 5.0 LCD TFT HMI Intelligent Touch Display 1 x Connecting Wires 1 x Power Supply Test Board Specifications :- Model No. NX8048T050 Display Type 011R(R:Resitive Touchscreen) Operating Voltage (VDC) 4.75 ~ 7 Max. Operating Current (mA) 410 Display Layout Size (L x W x H) mm 133.5 84 6.2 Net weight (gm) 128 Touch Type Resistive Colors 65K (65536) Recommended Power Supply 5V, 500mA, DC Working Temperature Range (C) -20 to 80 Working Humidity Range 10% to 90% RH USB Interface No Micro-SD Card Slot Yes (FAT32 format), support maximum 32G Micro SD Card Flash Memory 16 MB RAM 3584 BYTE
