Water Float Switch Type - 2 (Water Level Sensor)

A float sensor or a float switch is a sensor used to detect the level of liquid (water) in a tank. Normally the purpose of a float switch is to open or close a circuit as the level of a liquid rises or falls. Our float sensor has a magnet on the float (the moving part) and a reed switch on the stem (fixed part). So when the magnet comes near the reed switch the reed switch is activated and the circuit becomes closed. Specifications:- Switching Voltage: 100V Max Switching Voltage: 220V Switching Current: 0.5A Max Switching Current: 1.5A Max Contact Resistance : 100mΩ Temperature Rating: -10 / +85°C Package Includes:- 1 x Water Float Switch Type - 2 (Water Level Sensor)
